| MODEL |
|
| INPUT |
| Voltage Range |
+/- 25% at line input |
| Frequency |
50Hz +/- 10% |
|
| OUTPUT |
| Voltage(on battery) |
Simulated sine wave at 220V +/- 10% |
| AVR |
AVR automatically increase output voltage15% above input voltage, if -9% to -25% of nominal. AVR decrease output voltage15% below input voltage input voltage if +9% to 25% of nominal
|
| Transfer Time |
|
| |
|
|
| PHYSICAL |
| NEW Weight (Kg) |
15.0 Kg |
| Gross Weight (Kg) |
15.5kg |
| |
|
|
| BATTERY |
| Type |
Sealed, maintenance-free lead acid
|
| Typical Recharge Time |
10-12hours |
| Protection |
Automatic self –test & discharge protection, replace battery indicator
|
| |
|
|
| ALARM |
| Backup Time |
6-30 minutes depending on computer load)
|
| Battery Backup |
Slow beeping sound (once per 2 seconds) |
| Battery Low |
Rapid beeping sound once per 0.5second) |
| Overload |
Continuous beeping sound |
| |
|
|
| Environment |
| Ambient Operation |
|
| Audible Noise |
<40dBA(1 meter from surface) |
| Storage condition |
1500metre max |
|
| Transfer Time |
<10ms |
| Ambient Operation |
3500 meters max. Elevation,0-95% humility non-condensing,0-40C |
